Measurement:
- Moisture
- Ambient temperature
Typical Materials:
- Sand
- Stone
- Recycled asphalt pavement (RAP)
- Other aggregates
Unique Key Features:
- Rugged, hard-wearing design for abrasive materials
- Simple installation into aggregate bins
- Shape ensures good compaction of material presented for accurate measurement
Angled for Narrow Neck Bin
- Mount at a downward angle if the bin neck is small.
Belt conveyor
- Mount on belt conveyors.
Beneath the Bin
- Position below the bin gate in the main flow of the material.
Inside the Bin
- Mount in the side of the bin.
Neck of the Bin
- Fit in the neck of the bin.
Vibratory Feeder
- Please contact our technical team for advice.
Wide Bin
- Mount using the extended mounting sleeve to access the centre of the material flow.
0023 Hydro-Probe – Clamp Ring (for use with 0024A or 0024B)
0024A Hydro-Probe – Flanged Mounting Sleeve (for vertical mounting of sensor, requires 0023)
0024B Hydro-Probe – Flanged Mounting Sleeve in stainless steel (for vertical mounting of sensor, requires 0023)
0025 Hydro-Probe – Standard Mounting Sleeve
0026 Hydro-Probe – Extension Mounting Sleeve
0975A 4m Sensor Cable
0975AT Sensor Cable with Network Termination (4, 10, 25 and 50m)
0023 Hydro-Probe – Clamp Ring (for use with 0024A or 0024B)
0024A Hydro-Probe – Flanged Mounting Sleeve (for vertical mounting of sensor, requires 0023)
0024B Hydro-Probe – Flanged Mounting Sleeve in stainless steel (for vertical mounting of sensor, requires 0023)
0025 Hydro-Probe – Standard Mounting Sleeve
0026 Hydro-Probe – Extension Mounting Sleeve
0975A 4m Sensor Cable
0975AT Sensor Cable with Network Termination (4, 10, 25 and 50m)
Modbus to control system
Input / Output connections
Recommended field cabling:
- Six pairs twisted (12 cores total) screened (shielded) cable with 22 AWG, 0.35mm2 conductors
- Screen (shield): Braid with 65% minimum coverage plus aluminium/polyester foil
- Recommended cable types: Belden 8306, Alpha 6373
- Maximum cable run: 100m, separate to any heavy equipment power cables
