Unique Key Features:
- Designed to provide a simple method for connecting Hydronix moisture sensors and controls.
- Communicate with up to 16 Hydronix sensors using one standard Ethernet connection.
- Two options available, each kit comes with all necessary cabling.
- Ethernet Adapter Kit (EAK01): This option is suitable for customers who have their own 24V power supply located close to their sensors.
- Ethernet Power Kit (EPK01): this option provides a small power adapter module and power injector. Suitable for powering the sensor via power over ethernet.
Modbus to control system
Input / Output connections
Recommended field cabling:
- Six pairs twisted (12 cores total) screened (shielded) cable with 22 AWG, 0.35mm2 conductors
- Screen (shield): Braid with 65% minimum coverage plus aluminium/polyester foil
- Recommended cable types: Belden 8306, Alpha 6373
- Maximum cable run: 100m, separate to any heavy equipment power cables
