Measurement:
- Moisture
- Ambient temperature
Typical Materials:
- Food for human consumption
Unique Key Features:
- Food Safe sensor compliant to EN 1935/2004 requirements.
- Fitted flush before or after dryers, the floor of mixers, ducting or conveyors.
- Choice of measurement modes for optimum sensor performance.
Screw Conveyor
- Position on the upstroke of the blade at 30° from vertical.
Single / Twin Shaft Mixer
- Position on the end wall of the mixer, 30° from vertical.
5010 HMXT Fixing Plate Kit (Fixing Plate, Bolts and O-Ring), required
5015 HMXT Fixing Plate
5020 HMXT O-Ring
5025 HMXT Fixing Plate Bolts
5030 HMXT Blanking Plug – used to create a seal if HMXT is removed
Modbus to control system
Input / Output connections
Recommended field cabling:
- Six pairs twisted (12 cores total) screened (shielded) cable with 22 AWG, 0.35mm2 conductors
- Screen (shield): Braid with 65% minimum coverage plus aluminium/polyester foil
- Recommended cable types: Belden 8306, Alpha 6373
- Maximum cable run: 100m, separate to any heavy equipment power cables
