Measurement:
- Moisture
- Brix
- Ambient temperature
Typical Materials:
- Liquids
- Dissolved solids
- Powdered products
- Paints
- Pharmaceutical powders
Unique Key Features:
- Measurement > 50°Bx
- High temperature sensor for material operating range of up to 120°C.
- Shape ensures good compaction of material presented for precise measurement.
- Choice of measurement modes for optimum sensor performance.
Calandria / Pressure vessel
- Install into the bottom of vessel/pan or on the side of the vessel. Suitable for pressures from vacuum to 6 bar.
Pipeline
- Install into a pipeline.
3010 HPBX/HPSE Mounting Boss and Mounting Gasket (includes part 3020)
3020 HPBX/HPSE Mounting Gasket (spare part for Mounting Boss 3010)
3150 HPBX-SC Cleaning System connection kit 6mm – ¼″ BSP
0975A 4m Sensor Cable
0975AT Sensor Cable with Network Termination (4, 10, 25 and 50m)
Modbus to control system
Input / Output connections
Recommended field cabling:
- Six pairs twisted (12 cores total) screened (shielded) cable with 22 AWG, 0.35mm2 conductors
- Screen (shield): Braid with 65% minimum coverage plus aluminium/polyester foil
- Recommended cable types: Belden 8306, Alpha 6373
- Maximum cable run: 100m, separate to any heavy equipment power cables
